WBJEE 2023 Chemistry Question Paper with Answer Key PDF Download

WBJEE Questions

• 1.

  Which logic gate is represented by the following combinations of logic gates?


  • NAND

  • AND

  • NOR

  • OR
  View Solution

  ---

• 2.

  Figure shows the graph of angle of deviation \( \delta \) versus angle of incidence \( i \) for a light ray striking a prism. The prism angle is



  • \( 30^\circ \)

  • \( 45^\circ \)

  • \( 60^\circ \)

  • \( 75^\circ \)
  View Solution

  ---

• 3.

  The variation of density of a solid cylindrical rod of cross-sectional area \( a \) and length \( L \) is \( \rho=\rho_0 \frac{x^2}{L^2} \), where \( x \) is the distance from one end. The position of its centre of mass from \( x=0 \) is


  • \( \frac{2L}{3} \)

  • \( \frac{L}{2} \)

  • \( \frac{L}{3} \)

  • \( \frac{3L}{4} \)
  View Solution

  ---

• 4.

  Manufacturers supply a zener diode with zener voltage \( V_z=5.6\,\text{V} \) and maximum power dissipation \( P_{\max}=\frac14\,\text{W} \). This zener diode is used in the circuit shown. Calculate the minimum value of the resistance \( R_s \) so that the zener diode will not burn when the input voltage is \( V_{in}=10\,\text{V} \).


  • \( 98.56\,\Omega \)

  • \( 170.52\,\Omega \)

  • \( 306.21\,\Omega \)

  • \( 412.37\,\Omega \)
  View Solution

  ---

• 5.

  The number of undecayed nuclei \( N \) in a sample of radioactive material as a function of time \( t \) is shown in the figure. Which of the following graphs correctly shows the relationship between \( N \) and the activity \( A \)?


  • Option a

  • Option b

  • Option c

  • Option d
  View Solution

  ---

• 6.

  The velocity-time graph for a body of mass \( 10\,\text{kg} \) is shown. Work done on the body in the first two seconds of motion is


  • \( -9300\,\text{J} \)

  • \( 12000\,\text{J} \)

  • \( -4500\,\text{J} \)

  • \( -12000\,\text{J} \)
  View Solution
