AP PGECET 2023 Electrical Engineering Question Paper with Answer Key

AP PGECET Questions

• 1.

  The entropy of single crystalline Silicon at absolute zero will be:


  • 2

  • 1

  • 0

  • 10

  View Solution

  ---

• 2.

  The minimum amount of work required to operate a refrigerator which removes 1000 Cal heat at $0^\circ$C and rejects at $50^\circ$C will be:


  • 170 Cal

  • 120 Cal

  • 150 Cal

  • 183.15 Cal

  View Solution

  ---

• 3.

  1 mole of Argon gas is heated at constant pressure from 200 K to 600 K.
  If \( C_p = 4\ \text{cal} \cdot \text{deg}^{-1} \cdot \text{mol}^{-1} \), then the change in entropy will be:
  (Given \( \ln 3 = 1.09 \))


  • 4.36 Cal.deg$^{-1}$mol$^{-1}$

  • 2.76 Cal.deg$^{-1}$mol$^{-1}$

  • 3.34 Cal.deg$^{-1}$mol$^{-1}$

  • 5.39 Cal.deg$^{-1}$mol$^{-1}$

  View Solution

  ---

• 4.

  A number is selected randomly from each of the following two sets:
  {1, 2, 3, 4, 5, 6, 7, 8}, {2, 3, 4, 5, 6, 7, 8, 9}
  What is the probability that the sum of the numbers is 9?

  • \(\frac{1}{8}\)

  • \(\frac{1}{16}\)

  • \(\frac{3}{32}\)

  • \(\frac{7}{64}\)
  View Solution

  ---

• 5.

  Why is the equilibrium constant (K) temperature-dependent?


  • Because $\Delta G^\circ$ depends on T

  • Because pressure affects K

  • Because entropy is temperature-independent

  • Because fugacity coefficients change with T

  View Solution

  ---

• 6.

  Design an approach to estimate the activity coefficient of a component in a non-ideal liquid mixture:


  • Use the ideal gas law

  • Apply the Gibbs-Duhem equation with experimental data

  • Assume it equals mole fraction

  • Use the Second Law only

  View Solution
