GATE 2026 Civil Engineering(CE) Question Paper with Solution Pdf

The GATE 2026 Civil Engineering (CE) Question Paper with Solution PDF is available here. The GATE CE exam was scheduled for February 14, 2026, and was conducted in two shifts: Session 1 (Forenoon) from 9:30 AM to 12:30 PM and Session 2 (Afternoon) from 2:30 PM to 5:30 PM.

The GATE Civil Engineering exam is held in Computer Based Test (CBT) mode with a total duration of 3 hours. The question paper contains a total of 65 questions for 100 marks, divided into three main sections: General Aptitude (15 marks), Engineering Mathematics (13 marks), and Core Civil Engineering subjects (72 marks).

Based on the analysis of previous years' papers, the Civil Engineering question paper is typically expected to be of moderate difficulty. For candidates, attempting 55 to 65 questions with an accuracy of 85–90% is considered a safe target. Scoring around 60–70 marks is generally regarded as a good performance, which can help in securing admission to top IITs or recruitment by leading PSUs like IOCL, ONGC, and NTPC.

GATE 2026 CE Question Paper with Solution PDF (Memory Based)

GATE 2026 CE Question Paper with Solution PDF	Download	Check Solutions

Question 1:

Consider a soil sample where the following parameters are defined:

\(S\) = Soil suction head
\(K\) = Hydraulic conductivity
\(w\) = Moisture content

If the moisture content (\(w\)) of the soil increases, which of the following statements regarding the soil suction head (\(S\)) and hydraulic conductivity (\(K\)) is correct?

(A) Both \(S\) and \(K\) increase.
(B) Both \(S\) and \(K\) decrease.
(C) \(S\) increases while \(K\) decreases.
(D) \(S\) decreases while \(K\) increases.

View Solution

Question 2:

A clay deposit is found to have a natural water content and void ratio that corresponds to a pre-consolidation pressure (\(\sigma'_{p}\)) that is greater than the present effective overburden pressure (\(\sigma'_{o}\)). This clay is best classified as:

(A) OCC (Over Consolidated Clay)
(B) LCC (Lightly Consolidated Clay)
(C) NCC (Normally Consolidated Clay)
(D) Quick Clay

View Solution

Question 3:

For a two-lane, two-way highway, the length of a summit curve is ideally designed based on which parameter to ensure full operational efficiency (overtaking opportunities)?

(A) Lateral friction (\(f\))
(B) Centrifugal acceleration (\(a_c\))
(C) Stopping Sight Distance (SSD)
(D) Overtaking Sight Distance (OSD)

View Solution

Question 4:

In a rectangular open channel, a hydraulic jump occurs. The ratio of the post-jump depth (\(y_2\)) to the pre-jump depth (\(y_1\)) is measured to be 2. What is the Froude number (\(Fr_1\)) of the flow immediately before the jump?

(A) \(\sqrt{2}\)
(B) 1.5
(C) \(\sqrt{3}\)
(D) 2.5

View Solution

Question 5:

The Rational Method formula for estimating peak runoff is given as \(Q = \frac{CiA}{360}\). For the result \(Q\) to be in cubic meters per second (\(m^3/s\)), what must be the units of rainfall intensity (\(i\)) and catchment area (\(A\))?

(A) \(i\) in \(cm/hr\), \(A\) in \(km^2\)
(B) \(i\) in \(mm/hr\), \(A\) in \(km^2\)
(C) \(i\) in \(mm/hr\), \(A\) in hectares
(D) \(i\) in \(m/hr\), \(A\) in hectares

View Solution

Question 6:

Match the Gradually Varied Flow (GVF) profiles on a mild slope (\(M_1, M_2, M_3\)) with the nature of their water surface slope (\(dy/dx\)) relative to the flow direction.
Profile & Nature of Slope (\(dy/dx\))

P. \(M_1\) Profile & 1. Positive (Rising Curve)

Q. \(M_2\) Profile & 2. Negative (Drawdown Curve)

R. \(M_3\) Profile & 3. Positive (Rising Curve)
Select the correct classification:

(A) \(M_1\) is Rising, \(M_2\) is Rising, \(M_3\) is Falling
(B) \(M_1\) is Rising, \(M_2\) is Falling, \(M_3\) is Rising
(C) \(M_1\) is Falling, \(M_2\) is Rising, \(M_3\) is Falling
(D) \(M_1\) is Rising, \(M_2\) is Falling, \(M_3\) is Falling

View Solution
